Brushed 12V DC Gear Motor 100Kg.cm/3.3RPM w/ 1269:1 Rectangular Spur Gearbox

FGE-36124500-G1269
StepMotech
Rating
This is a standard 12 volt brushed DC gear motor, generating 100kg.cm of torque at 3.3rpm. It's a small, inexpensive motor suitable for low torque, high speed applications. Combined with a 1269 : 1 rectangular gearbox, this motor will provide greater efficiency, higher torque, and quieter motor operation.
$19.87
Quantity

Ask about the product on WhatsApp
Description

This is a standard 12 volt brushed DC gear motor, generating 100kg.cm of torque at 3.3rpm. It's a small, inexpensive motor suitable for low torque, high speed applications. Combined with a 1269 : 1 rectangular gearbox, this motor will provide greater efficiency, higher torque, and quieter motor operation.

Electrical Specification

  • Part Number: FGE-36124500-G1269
  • Rated Voltage: 12V
  • Rated Torque: 100kg.cm(1383oz.in)
  • Rated Current: <=1700mA
  • Rated Speed: 3.3rpm
  • No-load Current: <=300mA
  • No-load Speed: >=3.5rpm
  • Rotation Direction: CW/CCW
  • Motor Type: Brushed DC Motor

Gearbox Specification

  • Gearbox Type: Spur Gearbox
  • Gear Ratio: 1269 : 1

Physical Specification

  • Motor Size: Φ37.5 x 57.5mm
  • Gearbox Size: 119 x 70 x 33mm
  • Shaft Diameter: Φ9.5mm
  • Shaft Length: 27mm
Product Details
FGE-36124500-G1269

Data sheet

Rated Current(A)
1.7
Shaft Diameter(mm)
9.5
SKU_certificated
ISO, CE
Inventory Method
Dedicated Inventory
Shaft Length(mm)
27
Rated Speed(rpm)
3.3
Rated Voltage(V)
12
Gearbox Type
Spur Gearbox
Gear Ratio
1269
Output Shaft Type
D
Rated Torque(oz.in)
1383
Motor Type
Brushed DC Motor
Gearbox Shape
Rectangular
Rated Torque(kg.cm)
100
